HBP Series Dual Tower Heat Regenerative Desiccant Air Dryers

HBP Series Dual Tower Heat Regenerative Desiccant Air Dryers

Capacity
EconoTronic Dew Point Demand Control Included

Altec AIR’s HBP Series Heat Regenerative Desiccant Air Dryers also use heated air to regenerate the off-line tower. Additionally, a high-efficiency packaged blower assembly directs heated atmospheric air counter current through the desiccant bed, removing the water vapor collected from the previous drying cycle. Dew point spikes or heat bumps are mitigated by enabling the auxiliary cooling / stripping feature that uses a small percentage of dry process air (1.7%)

  • Industrial Duty Blower
  • ASME / CRN Approved Pressure Vessels
  • Factory installed Filters w/ Differential Pressure Gauges and Pre-Filter Timer Drain
  • Feature Rich ETL Listed Pro-Logic Controller w/ NEMA 4X Enclosure
  • Regulated Purge Flow for Optimum Setting, Regardless of Operating Pressure
  • ISO 8573.1 Class 2 -40°F/C Standard Outlet Dewpoint

FILES & LITERATURE:

  1. Specifications Sheet
  2. Large Capacity Desiccant Air Dryers Brochure
  3. Industrial Products Brochure

STANDARD FEATURES:

  • Power Requirements (model specific) -
    • 120 VAC, 1 Phase, 60 Hz
    • 230 VAC, 1 Phase, 60 Hz
    • 460 VAC, 3 Phase, 60 Hz
  • Maximum Pressure - 150 PSIG Standard
  • Maximum Operating Temperature - 120°F / 49°C
  • Tower Pressure Gauges & Dew Point Indicators
  • Welded Frame Base - Easy Move With Forklift
  • OSHA Approved Mufflers
  • Desiccant Fill & Drain Ports
  • ASME Safety Relief Valves

OPTIONAL FEATURES:

  • Alternate Voltages
  • EcoTronic Dew Point Demand Control
  • Dual Filter & Bypass Packages
    • 3-Way Bypass Installed
    • 6-Way Bypass w/ Dual Select Pre-Filter
    • 9-Way Bypass w/ Dual Select Pre & After Filters
  • Environment Temperature Protection Kits
  • High Pressure (200 PSIG) Models
  • Upgraded Controller
  • Stainless Steel Control Tube & Fittings
  • Bolt-Down Construction
